Thermal mass flow meter for lab gas

Thermal mass flow meter for lab gas

SRK-M Micro-flowrate Thermal gas mass flow meter is designed on the basis of thermal dispersion, and adopts method of constant differential temperature to measuring gas flow. It does not require external temperature and pressure compensation or correction to realize gas or air mass flow rate measurement. It has advantages of small size, easy installation, high reliability and high accuracy, etc. Micro mini thermal mass flow meter with modular construction is for laboratory purpose.

Features and specifications

Thermal mass flow meter sensor size: DN3 to DN10, suitable for gas flow measurement in the lab
Gas min flow starting from 0~21000 mL/min
Gas velocity range: 0.1~100 Nm/s
Gas flow meter accuracy: ±1~2.5%
Power supply: 24V DC
Output: 4-20mA (optoelectronic isolation, maximum load 500Ω), Pulse, RS485 ,Hart protocol
Alarm output: 2 line relays; Normally Open state, 3A/30V/DC
Digital display to show mass flow or gas volume flow at standard condtion,also gas flow velocity
Protection level: IP65
Thermal mass flow meter probe material: 316 stainless steel

Flow Range

DN(mm)

Min(mL/min)

Max(mL/min)

Min(L/h)

Max(L/h)

3

0.000

21000

0.000

1272

4

0.000

37000

0.000

2261

6

0.000

84000

0.000

5100

8

0.000

150000

0.000

9050

10

0.000

235000

0.000

14137


Micro gas flow meter for lab dimensions

lab gas flow meter size
