Insertable flow meter/insertion flow meter

We offer insertable flow meter for gas or liquid flow measurement for large pipeline measurement.

Insertable Magnetic flow meter-for liquid flow measurement

Insertable Magnetic flow meter-for liquid flow measurement
Insertion type electromagnetic flowmeter is a new type of flow meter developed on the basis of inline magnetic flowmeter. The installation of pipeline mag meter is difficult and expensive when the pipeline is large, such as 10”, 12” 16” pipeline, so we develop insertable electromagnetic flow meters for large pipe line .Insertion mag flow meter can be installed without cutting of the fluids flow, it can be mounted on cast iron pipes or cement pipes
The Insertion flow meter is used to measure conductive liquids, and is especially suitable for large size pipeline measurement. It is widely used in petroleum, chemical, metallurgy, power, papermaking, food, water treatment and other industries. The biggest advantage is that the anti-vibration performance is particularly good, no zero drift, and high reliability.

Features of Insertion type mag flow meter

  • Low power consumption
  • Low pressure loss
  • No moving parts and stable performance
  • Insertion eletromagnetic flow meter has simple structure, easy to install and maintain
  • Measurements are not affected by changes in fluid density, viscosity, temperature, pressure, and conductivity
  • The nominal diameter of the series is 6 inches~DN3000. Multiple choices for mag flow sensor liner and electrode materials
  • The mag flow converter can be integrated or separated with the flow sensor
  • Digital magnetic flow meter to show fluids total flow and flow rate
  • Bi-direction flow measurement: forward flow and reverse flow
  • Insertion Magnetic flow meter has multiple outputs: current, pulse, digital communication.
  • Digital communication signal output such as RS485, RS232, Hart and Modbus. (Optional)

Insertion thermal mass flow meter – for gas flow measurement

Insertion type thermal mass flow meter
The insertion type thermal mass flow meter is designed based on the principle of thermal diffusion. The gas flow measurement instrument uses the constant temperature difference method to accurately measure the gas. Comparing to inline type thermal flow meter, insertable gas flow meter is used in large pipeline gas or air measurement, it is used when the pipeline is over 4 inches.

What kind of gas can be detected and measured by insertion type thermal flow meter?

O2, N2, Hydrogen , blast furnace gas, coke oven gas, flume gas, biogas ,compressed air, natural gas, LPG.,etc

Advantages of insertion type thermal dispersion flow meter

  • Easy installation for insertion flow meter sensor, simple maintenance
  • Wide range ratio is 100: 1
  • No need other sensors to realize gas or air mass flow measurement, direct mass flow detection without temperature and pressure compensation.
  • The flow and temperature are detected and displayed simultaneously
  • Gas or air low flow can be used detected for leak detection.
  • Can be used as high temperature gas flow meter

  • Insertion air flow meterInsertion air flow meter2019/07/10Thermal mass flow meter is a suitable type insertion air flow meter which can detect air or compressed air flow rate in a closed pipeline or duct. Insertion style thermal dispersion flow meter is for ...view
  • Insertion Gas Flow MeterInsertion Gas Flow Meter2020/01/27An insertion gas flow meter is used to measure the flow rate of gases or liquid. A flow meter measures the amount of gas or liquid flowing through a pipeline and determines the flow which is equivalen...view
  • Insertion type electromagnetic flow meterInsertion type electromagnetic flow meter2019/06/27Insertion probe electromagnetic flow meter is suitable for pipeline size over 8 inches; it is ideal solution for large pipe size conductive liquid flow measurement ,such as waste water, portable water...view
  • Insertion type thermal mass flow sensorInsertion type thermal mass flow sensor2019/06/14Insertion probe thermal mass flow meter is for large pipeline size or ducts gas or air flow measurement, it is easy for users to install or removal from the mounting points without needing cut off the...view
  • SLH Series Insertion Type Ultrasonic Flow MeterSLH Series Insertion Type Ultrasonic Flow Meter2018/06/22SLH Series Insertion type ultrasonic flow meter consists of the transmitter and insertion transducer. Install the transducer by opening two holes on the pipeline. No need to cutoff water by using the ...view
  • Insertion vortex flow meterInsertion vortex flow meter2019/07/02Insertion vortex flow meter is designed for large pipeline size over 10 inches, users can install and removal the vortex sensor without closing down the whole running system. Customers can get volumet...view Protection Status
